4242
HCD-L1
6-19. Printed Wiring Board DISPLAY Section
• See page 25 for Circuit Boards Location.
Ref. No. Location
D1281 A-3
D1282 A-3
D1283 A-3
D1284 A-3
D1285 A-3
IC1201 A-6
Q1201 A-8
Q1281 A-1
Q1282 A-1
• Semiconductor
Location
(Page 34)
IC1201
