Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
57
SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
•Abbreviation
CND : Canadian model.
SP : Singapore model.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
HCD-L1
AMP
A-4728-118-A AMP BOARD, COMPLETE
********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C300 1-126-944-11 ELECT 3300uF 20.00% 25V
C301 1-216-864-11 METAL CHIP 0 5% 1/16W
C311 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C312 1-124-231-11 ELECT 4.7uF 20.00% 16V
C314 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C315 1-124-231-11 ELECT 4.7uF 20.00% 16V
C316 1-124-249-91 ELECT 0.1uF 20.00% 50V
C320 1-104-662-11 ELECT 22uF 20% 16V
C321 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C322 1-162-908-11 CERAMIC CHIP 3.0PF 5% 50V
C323 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C324 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C330 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C331 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C332 1-104-665-11 ELECT 100uF 20.00% 10V
C333 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C334 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C335 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C336 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C338 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C339 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C340 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C341 1-104-665-11 ELECT 100uF 20.00% 10V
C342 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C343 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C351 1-137-372-11 MYLAR 0.022uF 5.00% 50V
C352 1-104-665-11 ELECT 100uF 20.00% 10V
C353 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C354 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C355 1-137-807-31 ELECT 100uF 20.00% 50V
C356 1-136-177-00 MYLAR 1uF 5.00% 50V
C357 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C358 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C360 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C361 1-137-372-11 MYLAR 0.022uF 5.00% 50V
C363 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C366 1-136-177-00 MYLAR 1uF 5.00% 50V
C367 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C370 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C371 1-137-372-11 MYLAR 0.022uF 5.00% 50V
C372 1-104-665-11 ELECT 100uF 20.00% 10V
C373 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C375 1-137-807-31 ELECT 100uF 20.00% 50V
C376 1-136-177-00 MYLAR 1uF 5.00% 50V
C377 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C378 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C380 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C381 1-137-372-11 MYLAR 0.022uF 5.00% 50V
C383 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C386 1-136-177-00 MYLAR 1uF 5.00% 50V
C387 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C390 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C392 1-109-982-11 CERAMIC CHIP 1uF 10.00% 10V
C393 1-109-982-11 CERAMIC CHIP 1uF 10.00% 10V
C400 1-126-964-11 ELECT 10uF 20.00% 50V
C401 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C402 1-126-964-11 ELECT 10uF 20.00% 50V
C403 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C404 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C405 1-126-964-11 ELECT 10uF 20.00% 50V
C415 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C435 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C450 1-126-964-11 ELECT 10uF 20.00% 50V
C451 1-162-964-11 CERAMIC CHIP 0.001uF 5% 50V
C452 1-126-968-11 ELECT 100uF 20.00% 50V
C460 1-126-964-11 ELECT 10uF 20.00% 50V
C461 1-162-964-11 CERAMIC CHIP 0.001uF 5% 50V
C470 1-126-964-11 ELECT 10uF 20.00% 50V
C471 1-162-964-11 CERAMIC CHIP 0.001uF 5% 50V
C472 1-126-968-11 ELECT 100uF 20.00% 50V
C480 1-126-964-11 ELECT 10uF 20.00% 50V
C481 1-162-964-11 CERAMIC CHIP 0.001uF 5% 50V
< CONNECTOR >
CN300 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN301 1-784-745-11 FFC CONNECTOR, 23P
< DIODE >
D350 6-500-131-01 DIODE LI116
D351 6-500-248-01 DIODE SFPL-62V
D352 6-500-055-01 DIODE P6SMB33AT3
D360 6-500-131-01 DIODE LI116
D361 6-500-248-01 DIODE SFPL-62V
