20
Identifying parts
A Eyecup (86)
B Eyepiece sensors (86)
C Viewfinder*
• When you look into the
viewfinder, the viewfinder
mode is activated, and when
you take your face away from
the viewfinder, the screen mode
returns to the LCD monitor
mode.
D Diopter-adjustment dial (35)
E LCD monitor (79, 90, 159)
F Light sensor (178)
G Multi-selector
H For shooting: Fn (Function)
button (59, 60)
For viewing: (Image
rotation) button (161)
I DISP (Display) button (87,
159)
J (Smart teleconverter)
button (153)/Focus Magnifier
button (124)
K (In-Camera Guide) button
(70)
For viewing: (Delete) button
(40)
L (Playback) button (39)
* Do not directly touch this
part.
Rear side
