Sony SRG-A40 User Manual

12
System Configuration
This camera can be arranged into various system configurations with other products (not supplied). This
section describes typical system examples with the required components and the main usage of each
system.
Operating a Single Camera Using the Supplied Remote
Commander
What you can do with this system
Operate the camera readily from a short distance.
System Configuration
Operating a Single Camera Using the Computer Browser
What you can do with this system
Refer to “Accessing the Camera from a Web Browser” (page 48).
System Configuration
Remote commander
(supplied)
Video monitor
Video signal
Signal flow
Network
Video monitor
Video signal
Signal flow
Computer
Web
browser

Sony SRG-A40 Specifications

General

Megapixel	8.5 MP
Camera type	Single camera
Sensor type	CMOS
White balance	Auto, Indoor, One push, Outdoor
Zoom capability	Yes
Gain control type	Auto/Manual
Focal length range	4.4 - 88 mm
Optical sensor size	1/2.5 \
Aperture range (F-F)	2 - 3.8
Light exposure modes	Auto, Manual
Minimum illumination	1.6 lx
Maximum working distance (tele)	800 mm
Minimum working distance (wide)	80 mm
Maximum frame rate	60 fps
Video formats supported	H.264, H.265
Maximum video resolution	3840 x 2160 pixels
Supported graphics resolutions	640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Pan range	-170 - 170 °
Product color	White
Pan speed (max)	300 °/sec
Tilt angle range	-20 - 90 °
Tilt speed (max)	126 °/sec
Bit rate control	Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Supported protocols	IPv4, IPv6, TCP, UDP, ARP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, VISCA over IP, SRT
Multi-stream capability	3
Audio channels	2
Ethernet LAN (RJ-45) ports	1
DC input voltage	19.5 V
Power source type	DC, PoE
Power consumption (typical)	80 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of screws	6

Weight and Dimensions

Depth	200 mm
Width	156.7 mm
Height	184 mm
Weight	2000 g
