Sony SRG-A40 User Manual

2
Table of Contents
Overview
Using This Manual ....................................... 4
Precautions for Preventing Access to the
Camera by an Unintended Third Party .........5
Privacy Notice ..............................................5
Notes on Usage ............................................5
Features ...................................................... 6
Location and Function of Parts
Camera .........................................................7
Infrared Remote Commander (supplied) ...10
System Configuration
Operating a Single Camera Using the
Supplied Remote Commander ................... 12
Operating a Single Camera Using the
Computer Browser ..................................... 12
Operating a Single Camera Using the
Optional Remote Controller ....................... 13
Operating Multiple Cameras Using the
Optional Remote Controller .......................14
Installation and Connection
Installing the Camera ................................. 15
Installing the camera on a desk ............ 15
Attaching the Camera to a Tripod ........ 15
Installing the Camera Using the M3
Fixing Screw Holes ................................ 15
Installing the camera on the ceiling ..... 15
Using the supplied URL label ................16
Connecting the Camera .............................19
Connecting to an AC power supply ......19
Connecting the camera to a PoE++
(Power over Ethernet Plus Plus) power
supply device ........................................19
Connecting a single camera to a
switcher, recorder, or monitor .............. 20
Connecting a single camera to a single
remote controller (not supplied) ........... 21
Connecting multiple cameras to a single
remote controller (not supplied) ........... 21
Connecting a commercially available
video switcher .......................................23
Connecting to commercially-available
microphones, etc. ..................................24
Operations Using the Supplied Infrared
Remote Commander
Before Starting Operations ....................... 25
Turning on the Power ................................ 25
Operating Multiple Cameras Using the
Infrared Remote Commander ................... 25
Pan/Tilt Operation ..................................... 26
Zoom Operation ........................................ 26
Focusing on a subject ................................ 26
Storing the Camera Settings in Memory
– Preset Feature ..........................................27
Storing the camera status .................... 27
Recalling the stored status ................... 27
Operating OSD (On-Screen Display)
Menus ....................................................... 28
Displaying an OSD menu ...................... 28
Returning to the main menu ................ 28
Canceling an OSD menu ....................... 28
Adjusting and Configuring the Camera
through On-Screen Menus
About On-Screen Menus ........................... 29
Confirming selection of menu items and
settings/Executing operations ............. 29
Main menu ............................................ 29
Setting menu ........................................ 30
Status .................................................... 30
EXPOSURE Menu ....................................... 30
COLOR Menu ............................................. 33
DETAIL Menu ............................................. 34
VISIBILITY ENHANCER Menu ...................... 35
ZOOM/FOCUS Menu (SRG-A40) ................ 35
ZOOM .................................................... 35
FOCUS ................................................... 35
FOCUS Menu (SRG-A12) ............................. 36
PICTURE/OPTICAL FILTER Menu .................37
PICTURE ................................................. 37
OPTICAL FILTER ..................................... 37
PAN TILT/PRESET RECALL Menu ................ 38
PAN TILT ................................................ 38
PRESET RECALL ..................................... 39
VIDEO OUT Menu ...................................... 40
HDMI .....................................................40
SYSTEM Menu ............................................ 40
STATUS Menu ............................................ 42
DEVICE INFO (Device information of the
camera and setting status of switches
on the back of the camera) .................. 42
NETWORK .............................................. 42
Menu Configuration .................................. 44

Sony SRG-A40 Specifications

General

Megapixel	8.5 MP
Camera type	Single camera
Sensor type	CMOS
White balance	Auto, Indoor, One push, Outdoor
Zoom capability	Yes
Gain control type	Auto/Manual
Focal length range	4.4 - 88 mm
Optical sensor size	1/2.5 \
Aperture range (F-F)	2 - 3.8
Light exposure modes	Auto, Manual
Minimum illumination	1.6 lx
Maximum working distance (tele)	800 mm
Minimum working distance (wide)	80 mm
Maximum frame rate	60 fps
Video formats supported	H.264, H.265
Maximum video resolution	3840 x 2160 pixels
Supported graphics resolutions	640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Pan range	-170 - 170 °
Product color	White
Pan speed (max)	300 °/sec
Tilt angle range	-20 - 90 °
Tilt speed (max)	126 °/sec
Bit rate control	Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Supported protocols	IPv4, IPv6, TCP, UDP, ARP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, VISCA over IP, SRT
Multi-stream capability	3
Audio channels	2
Ethernet LAN (RJ-45) ports	1
DC input voltage	19.5 V
Power source type	DC, PoE
Power consumption (typical)	80 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of screws	6

Weight and Dimensions

Depth	200 mm
Width	156.7 mm
Height	184 mm
Weight	2000 g
