Sony SRG-A40 User Manual

83
Stream Menu
Stream
Note
When the Streaming tab settings are changed, RTSP streaming is temporarily interrupted. Therefore, the
screen turns black for a moment when the viewer is displayed on other web browsers.
Stream Setting
RTSP
This setting item is displayed when [Stream Setting] is set to [RTSP].
Make settings related to RTSP Streaming.
Menu item Detail and setting
value
Initial setting value
of the factory
default setting
Content
Setting RTSP/SRT-Caller/
SRT-Listener/
NDI|HX/Off
RTSP The setting items corresponding to the selected
mode are displayed.
Menu item Detail and setting
va
lue
Initial setting value
of the factory
default setting
Content
Port Number 554, 1024 to 65534 554 Set the port number for RTSP.
Time Out 0 to 600 60 Specify the time for time out by the Keep-Alive
c
ommand from RTSP streaming.
At the [0] setting, time out of the Keep-Alive
c
ommand is not available.
Authentication On/Off On Set whether or not to perform user authentication for
RTSP streaming. When enabled, the user name and
password set in [User] will be authenticated. The
viewer cannot be displayed unless the correct user
name and password are entered.
Notes
• The RTSP authentication setting affects acquisition
of the RTSP streaming on programs other than a
web browser. When you want to prevent getting
the streaming by users other than the ones you
set, set [Authentication] to On to use the camera.
• When the setting is changed, RTSP streaming is
te
mporarily interrupted. Therefore, the screen
turns black for a moment when the viewer is
displayed on other web browsers.
Video Port
Num
ber 1
1024 to 65534 51000 Specify the transmission port number for video data
used for RTSP unicast streaming.
Video Port
Number 2
1024 to 65534 53000 Specify an even number in the setting range. Two port
numbers (the number specified here and an odd
number with 1 added to the specified number) are
actually used for video data communication and
control. When performing simultaneous multi-
transmissions, a different port number will be used
for every transmission, based on the port number
specified here.

Sony SRG-A40 Specifications

General

Megapixel	8.5 MP
Camera type	Single camera
Sensor type	CMOS
White balance	Auto, Indoor, One push, Outdoor
Zoom capability	Yes
Gain control type	Auto/Manual
Focal length range	4.4 - 88 mm
Optical sensor size	1/2.5 \
Aperture range (F-F)	2 - 3.8
Light exposure modes	Auto, Manual
Minimum illumination	1.6 lx
Maximum working distance (tele)	800 mm
Minimum working distance (wide)	80 mm
Maximum frame rate	60 fps
Video formats supported	H.264, H.265
Maximum video resolution	3840 x 2160 pixels
Supported graphics resolutions	640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Pan range	-170 - 170 °
Product color	White
Pan speed (max)	300 °/sec
Tilt angle range	-20 - 90 °
Tilt speed (max)	126 °/sec
Bit rate control	Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Supported protocols	IPv4, IPv6, TCP, UDP, ARP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, VISCA over IP, SRT
Multi-stream capability	3
Audio channels	2
Ethernet LAN (RJ-45) ports	1
DC input voltage	19.5 V
Power source type	DC, PoE
Power consumption (typical)	80 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of screws	6

Weight and Dimensions

Depth	200 mm
Width	156.7 mm
Height	184 mm
Weight	2000 g
