CHASSIS 5-5
• Disconnect the brake light/taillight lead wire coupler
2.
• Unhook the seat lock cable
3.
• Remove the seat tail cover.
FRAME HEAD COVER (GSF650)
• Remove the frame head cover
1 (LH and RH).
": Hooked point
COWLING AND COWLING BRACE (GSF650S)
• Remove the caps.
• Remove the rear view mirrors (LH and RH).
• Remove the combination meter unit.
• Remove the wind screen
1 and upper panel
2.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki GSF650S and is the answer not in the manual?

Suzuki GSF650S Specifications

General IconGeneral
Engine Type4-stroke, 4-cylinder, liquid-cooled, DOHC
Bore x Stroke65.5 mm x 48.7 mm
Compression Ratio11.5:1
Fuel SystemFuel injection
IgnitionElectronic ignition (transistorized)
Transmission6-speed constant mesh
Final DriveChain
Front SuspensionTelescopic, coil spring, oil damped
Rear SuspensionLink type, coil spring, oil damped
Displacement656 cm³
Front BrakesDisc
Rear BrakesDisc
Front Tire120/70ZR17
Rear Tire160/60ZR17
Fuel Tank Capacity19 liters
Seat Height790 mm
