CHASSIS 5-11
WHEEL BEARINGS
• Apply grease to the bearing before installing.
' 99000-25010: SUZUKI SUPER GREASE “A”
• Install the wheel bearing using the used bearing and special
tool.
% 09924-84521: Bearing installer set
$
• Make sure that the brake discs are clean and free of any
grease. Apply THREAD LOCK SUPER “1360” to the brake
disc bolts and tighten them to the specified torque.
( 99000-32130: THREAD LOCK SUPER “1360”
# Brake disc bolts: 23 N·m (2.3 kgf-m)
WHEEL
• Install the front wheel and tighten the front axle temporarily.
)
* First install the left bearing, then install the spacer
and right wheel bearing.
* The sealed cover of the bearing must face outside.
The directional arrow on the wheel and tire must point
to the wheel rotation, when remounting the wheel.

Suzuki GSF650S Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Bore x Stroke	65.5 mm x 48.7 mm
Compression Ratio	11.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Displacement	656 cm³
Front Brakes	Disc
Rear Brakes	Disc
Front Tire	120/70ZR17
Rear Tire	160/60ZR17
Fuel Tank Capacity	19 liters
Seat Height	790 mm
