5-32 CHASSIS
• Remove the sprocket mounting drum bearing and wheel bear-
ings using the special tool.
% 09921-20240: Bearing remover set
$
WHEEL DAMPERS
Inspect the dampers for wear and damage.
Replace the damper if there is anything unusual.
• Remove the brake disc.
REAR SPROCKET
Inspect the rear sprocket teeth for wear. If they are worn as
shown, replace the engine sprocket, rear sprocket and drive
chain as a set.
The removed dust seal and bearing must be replaced
with new ones.
Normal wear Excessive wear

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki GSF650S and is the answer not in the manual?

Suzuki GSF650S Specifications

General IconGeneral
Engine Type4-stroke, 4-cylinder, liquid-cooled, DOHC
Bore x Stroke65.5 mm x 48.7 mm
Compression Ratio11.5:1
Fuel SystemFuel injection
IgnitionElectronic ignition (transistorized)
Transmission6-speed constant mesh
Final DriveChain
Front SuspensionTelescopic, coil spring, oil damped
Rear SuspensionLink type, coil spring, oil damped
Displacement656 cm³
Front BrakesDisc
Rear BrakesDisc
Front Tire120/70ZR17
Rear Tire160/60ZR17
Fuel Tank Capacity19 liters
Seat Height790 mm
