5-2 CHASSIS
EXTERIOR PARTS REMOVAL AND
REMOUNTING
FRONT FENDER
With the bolts removed, remove the front fender.
LUGGAGE BOX
Remove the luggage box as shown in illustration.
FRONT SEAT
Remove the front seat with the ignition key.
REAR SEAT
Remove the front seat.
With the bolts removed, remove the rear seat.
Luggage box
Tool holder
