CHASSIS 5-3
RIGHT FRAME CO
VER
•
Remove the bolt.
•
With the hooks
A
remo
ved, remo
ve the right frame co
ver
.
FRAME CO
VER
RIGHT REAR FRAME CO
VER
•
Remo
ve the right frame co
ver
.
•
With the screw and bolts removed, remove the right rear frame
co
ver
.
Frame head cover
Rear frame cover
R & L
Upper frame cover R &L
Frame cover
R & L
Left side only
129
131
