5-42 CHASSIS
REAR BRAKE
REMO
V
AL AND DISASSEMBL
Y
•
Remo
ve the rear wheel.
(
9
5-36)
•
Remo
ve the rear br
ake panel.
•
Remo
ve the br
ake shoes
.
•
Remo
ve the rear br
ake cam le
ver
1
and rear brak
e cam
2
by
removing n
ut.
•
Remo
ve the w
asher
3
and O-ring
4
.
