Suzuki VL125 Service Manual

3-46 ENGINE
CRANKCASE
BEARING INSPECTION
Rotate the bearing inner race by finger to inspect for abnormal
play, noise and smooth rotation while the bearings are in the
crankcase.
Replace the bearing in the following procedure if there is any-
thing unusual.
DISASSEMBLY
• Remove the oil nozzle 1.
RIGHT CRANKCASE BEARING
• Remove the bearing retainer.
• Remove the bearings 1, 2 and 3.
% 09921-20220: Bearing remover set
(1:
φ 20, 2: φ 25, 3: φ 17)
• Remove the bearing 4.
% 09913-75520: Bearing installer set (
φ 55)
NOTE:
If abnormal noise does not occur, it is not necessary to remove
the bearing.
7
The removed bearing should be replaced with a new
one.

Suzuki VL125 Specifications

General

Displacement	124 cc
Ignition	Electronic ignition (CDI)
Starter	Electric
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm, coil spring, oil damped
Rear Brake	Drum
Overall Length	2, 080 mm
Overall Width	760 mm
Ground Clearance	150 mm
Fuel System	Carburetor
Front Brake	Single disc
Front Tire	90/90-18
Seat Height	735mm
