4.3 Working with the Web Interface
This section provides an overview of the web interface (Web UI). Refer to
the Help for detailed instructions.
When you connect to a base station, the browser displays a page like the
following:
The accordion menu on the left gives you access to the various pages. Click
a top level item (such as Configure) to open up its menu. Click on a menu
item to display its page, then click on the appropriate tab on that page to
display the required information. Click the ( ) icon on a menu item to
expand the menu tree and the ( ) icon to collapse it again.
Using a browser window size smaller than 1024 x 768 may cause some
pages to display incorrectly.
Accordion menu
Model and name of
base station
Alarm status. Click
System Status to go to
the Alarms screen
Displays the
configured software
application
Click to
disconnect
Status bar
Click your user name
to change your
password and user
settings
