TB7300 Installation and Operation Manual Installation 59
© Tait International Limited December 2022
5.4 Initial Setting Up
Before putting the base station into service, you may want to carry out
some basic functional testing, configuration, and tuning (if required). This
section provides an overview of these procedures:
■ Checking that the base station powers up correctly
■ Checking the basic functionality of the base station by using the tests
available in the web interface
■ Customizing the configuration for the intended installation and
verifying that the configuration is correct
■ Changing the root password
■ Tuning the base station, if required
5.4.1 Confirming Operation
Notice The RF output must be connected to a suitable attenuator or
dummy load. Do not remove the load while the PA is transmitting as
this may damage the PA output stage.
Applying Power 1. Apply power to the TB7300.
2. Check that the base station powers up correctly:
All LEDs turn on initially, then the transmit and receive LEDs turn
off, leaving the green power LED on, and the red alarm LED flash-
ing. The alarm LED will turn off when the base station has finished
its start-up sequence.
Functional Tests The following table provides an overview of the tests available using the
Web UI. Refer to the base station Help for full details of these tests.
Test Notes Menu
Receiver operation Requires a suitable RF source Diagnose > RF Interface > Receiver
Transmitter operation Requires connection to the
network
Diagnose > RF Interface > Transmitter
Ping Checks the IP connection to
another device with an IP address
Diagnose > Connection > Network
NTP query Checks if the NTP-based time
synchronization is working
