TC-Helicon Voicelive 2 User Manual

The Pitch Button
Pressing the Pitch button activates auto chromatic
pitch correction. For most applications, this is all that is
required to set this feature. There is no need to set Key
or Scale; all notes that you sing in the 12 tone western
chromatic scale are corrected to the nearest scale tone.
This type of vocal pitch correction is quite subtle at its
factory setting of 50% but even the most highly skilled
and on-pitch singers will hear a slight chorusing from the
PA or monitors with it engaged.
Press and hold the Pitch button to access the PITCH tab
and adjust the single parameter for this feature. Once
you see this tab, the Pitch button can be cycled on and
off to allow you to hear the difference. Press the Home
button to exit the Pitch edit tab.
AUTO-CHROMATIC AMOUNT
The factory default value of 50% is active when you
enter the PITCH edit tab. Turning the control towards
0% reduces the correction effect and turning towards
100% increases. Above 50% the effect becomes more
noticeable when you slide from note to note. This is
the effect of faster transition speed between your input
note and the closest scale tone as well as the fact that
the algorithm is trying to pull you closer to the target.
For those singers who want to use or experiment with
scale-based pitch correction and perhaps even the
jagged, modern HardTune effects, there are presets
set up specifically for this that can be found by
pressing the Wizard button and choosing CORRECT or
HARDTUNE as the Tag.
The Global Controls: Pitch
48

TC-Helicon Voicelive 2 Specifications

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Power

external power supply mains voltage	100 to 240 VAC, 50 to 60 Hz
power consumption	<14 W

Analog Inputs

mic input impedance	2.14/1.07 kOhm
line input impedance	13/6.5 kOhm
guitar input impedance	1 MOhm

Analog Outputs

output impedance	100/50 Ohm
output range	16 dBu / 0dBu
dynamic range	> 109 dB, 20 Hz to 20 kHz

Weight and Dimensions

dimensions	13.8" x 3" x 8.5" (350 x 76 x 216)
weight	5 lb. (2.3 kg)
