TC-Helicon Voicelive 2 User Manual

The EQ Tab
Use the Navigate arrows to tab over to the EQ tab
from the GUITAR tab. Here you will find a 3 band EQ
featuring:
Low band shelving
All band fully parametric peak/dip control
High band shelving
The 2 “Shelving” EQs boost or cut all frequencies below
or above the the frequencies set by the LOW FREQ
and HIGH FREQ controls respectively. These are most
like the common Bass and Treble controls on a stereo
system.
The “Parametric” EQ boosts or cuts the frequencies
within a selected band that is defined by a center
frequency (PARA FREQ) and a width control (PARA
WIDTH). Usually, the gain of a narrow parametric band
is typically reduced to overcome room or undesirable
guitar resonances. This smoothes the sound and can
help overcome guitar feedback.
The 3 GAIN controls allow +/- 12 dB of adjustment.
The 3 FREQ controls range from 20 Hz to 20 kHz.
LOW GAIN
Boosts or cuts the range of frequencies below the
frequency set by the LOW FREQ control.
LOW FREQ(uency)
Allows you to define the frequency range for the low
shelf by choosing the highest frequency below which
boosting or cutting is possible.
HIGH GAIN
Boosts or cuts the range of frequencies above the
frequency set by the LOW FREQ control.
HIGH FREQ
Defines the frequency range for the high shelf with the
selection of the lowest frequency above which boosting
or cutting is possible.
The Global Controls: Guitar FX
51

TC-Helicon Voicelive 2 Specifications

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Power

external power supply mains voltage	100 to 240 VAC, 50 to 60 Hz
power consumption	<14 W

Analog Inputs

mic input impedance	2.14/1.07 kOhm
line input impedance	13/6.5 kOhm
guitar input impedance	1 MOhm

Analog Outputs

output impedance	100/50 Ohm
output range	16 dBu / 0dBu
dynamic range	> 109 dB, 20 Hz to 20 kHz

Weight and Dimensions

dimensions	13.8" x 3" x 8.5" (350 x 76 x 216)
weight	5 lb. (2.3 kg)
