TC-Helicon Voicelive 2 User Manual

Overview
The delay effect is a configurable echo. You can control
how far apart the echoes occur (Delay Time), and
whether the echoes fade out quickly or slowly or build
on themselves. In addition, there are filtering and stereo
controls that allow you to create many popular delay
sounds. Delays can be typically be categorized into the
two listed categories below:
Short Delays:
o Initial reflections
o Slaps
Long Delays (max stereo delay is 2500 ms or 2.5 sec.)
o Mono taps
o Stereo taps
o Syncopated taps
o Ping-pongs (delays travelling from left to right)
STYLE
Use the soft knob assigned to this parameter to choose
a pre-programmed delay style you like.
LEVEL
Sets the mix level for the delay effect.
WIDTH
The 2 delay lines are panned hard left and right. This
allows you to determine the stereo imaging of the delay
effect. 0% is mono, 100% is fully stereo.
SOURCE
Determines which of the three methods you want to
use to set delay times. These include:
TIME: This allows you to set the exact delay time for the
left and right delay lines manually with the TIME L and
TIME R controls.
TAP: This allows you to tap the SHORTCUT footswitch
when it is assigned to TEMPO in the PRESET tab.
The Edit Menu: DELAY Tab
57

TC-Helicon Voicelive 2 Specifications

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Power

external power supply mains voltage	100 to 240 VAC, 50 to 60 Hz
power consumption	<14 W

Analog Inputs

mic input impedance	2.14/1.07 kOhm
line input impedance	13/6.5 kOhm
guitar input impedance	1 MOhm

Analog Outputs

output impedance	100/50 Ohm
output range	16 dBu / 0dBu
dynamic range	> 109 dB, 20 Hz to 20 kHz

Weight and Dimensions

dimensions	13.8" x 3" x 8.5" (350 x 76 x 216)
weight	5 lb. (2.3 kg)
