Overview. Use this dialog box to save a time stamp to a file.
To use.
1. Under Save What, click Timestamp.
2. Click the Timestamp Options button to set the Source and FastFrame Data Range for the time stamp.
3. Name the file and set the Save as type parameters for the timestamp you want to save.
4. Click the Save button to accept any changes and close the dialog box.
Behavior. Timestamp data is saved in C:\Users\[Username]\Tektronix\TekScope\data unless you select a
different location.
TIP. You can conveniently save time stamps from the FastFrame Control Window by using the Acquisition > FastFrame >
Analyze tab > Save button.
What do you want to do next?
Learn about saving waveforms.
Learn about saving screen captures.
Learn about saving measurements.
File menu
546 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
