To use. For information on the controls, click the buttons.

■

Trigger Type

■

Mark All Trigger Events

■

Settings

■

Source

■

Set to 50%

■

Level

■

Timer

■

Trigger When

■

Qualification

■

Pattern

■

Edit Button

■

HF Filtering

■

Envelope

NOTE. The Trigger Timeout screen on DPO and MSO instruments is the same except for the source selection (MSO instruments

include digital channels) and Trigger if Timeout Qualification options. In some instruments, the source selection is a drop-down

list and the Trigger if Timeout Qualification option has Occurs and Logic. In other instruments the source selection includes a

combo list and a Select button. The Trigger if Timeout Qualification option has Occurs, Logic, and Occurs And.

The following Trigger Timeout screen appears on MSO70000C/DX and DPO7000C Series instruments:

The following Trigger Timeout screen appears on DPO70000SX Series instruments:

Trigger setups

DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 431
