NIST USGCB compliance. Tektronix oscilloscopes are compatible with the security configuration for Information Technology
products specified in the United States Government Configuration Baseline (USGCB) settings for Windows 7 and Internet
Explorer.
The National Institute of Standards and Technology (NIST) USGCB baseline operating system security requirements (Version
1.1.x) were implemented and tested on our oscilloscopes. The oscilloscopes passed the Security Content Automation Protocol
(SCAP) tests. Our oscilloscopes operate with the USGCB security settings implemented.
NOTE. Since the USGCB turns off the ISS server, LXI Class C compliance does not work with this data security standard.
As shipped from the factory, your oscilloscope has none of the USGCB security settings implemented.
Making your oscilloscope compliant. To put their oscilloscope in a USGCB compliant state, follow instructions from the NIST
Web site. Click on the Content and then Microsoft Content links. Implement the settings in the GPO files found on the site. After
implementing all of the settings, run the SCAP tool to verify compliance.
Restoring your oscilloscope to its factory state. To back out of the USGCB compliant state and restore the oscilloscope to its
factory condition, follow the Operating System Restore procedures for your instrument. See you user manual.
Hard copy printing. To make hard copies, use a printer attached to one of the rear-panel ports or connect to a network printer, if
your instrument is on a network.
You can print the full screen or just the graticule area.
The instrument uses Windows print drivers, so the process to install printers is the same as it is on any other PC.
The Page Setup dialog box contains some useful options to optimize your printing:
■
Choose a print palette that is independent from the display palette. For example, you can print gray-scale images to a black
and white laser printer while you choose to view the display in color. The color and gray scale palettes both render the
intensity-graded waveform information generated by the DPO display.
■
Choose the Ink Saver feature to print a hard copy with a white background. This function saves printer ink while it preserves
the color coding of the waveforms and readouts. Ink Saver also works with the monochrome print palettes.
Other PC applications. Transferring images and data from the oscilloscope to other PC applications is as simple as a copy/
paste operation. With a word processing, spreadsheet, or analysis application running on the built-in PC, you can easily transfer
the following items using the familiar Windows clipboard system:
■
Copy a full screen or graticule-only image, and paste it into your document in either .bmp, .png, .tif, or .jpg format.
■
Copy a waveform, and paste the waveform data into a spreadsheet in a comma-delimited (.csv) format.
■
Copy a waveform, and paste the waveform data into an analysis program in Mathcad (.dat) format.
■
Copy the displayed values of all measurements, and paste them into a document in text (.txt) format.
■
Copy the displayed values of all measurements, and paste them into a spreadsheet in a comma-delimited (.csv) format.
About Tektronix oscilloscopes
26 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
