Save and Recall I
nformation
Save
Screen
3. From the side-bezel menu, push F ile
Format repeat
edly to select among: .tif,
.bmp, and .png formats.
File
Format
.png
4. Push Orienta
tion to select between saving
the image in a landscape (horizontal) and a
portrait (vertical) o rientation.
Orientation
5. Push Ink Saver to turn the Ink Saver mode
on or off. When on, this mode provides a
white background.
Ink Saver
On |
Off
6. Push Edit File N ame to create a custom
name for the screen image file. Skip this
step to use a default name.
Edit File
Name
7. Push OK Save Screen Image to write the
image to the selected media.
OK Save
Screen
For information on printing screen images of waveforms, go to Printing a H ard C opy. (See page 171, Printing a Hard Copy.)
Saving and Recalling Waveform and Trace Data
Waveform and trace data consists of the numeric values for each point in the waveform or trace. It copies the data, as
oppose
d to a graphical image of the screen. To save the c urrent waveform or trace data or to r ecall previously stored
waveform or trace data:
1. Push Save / Recall M enu.
2. Push
Save Waveform or Recall Waveform
from the lower-bezel menu.
Save
Screen
Save
Waveform
Save
Setup
Recall
Wavef
orm
Recall
Setup
Assign
Save|to
Waveform
File
Utili
ties
NOTE
. The oscilloscope can save digital
waveforms to .csv files, not reference memories.
The o scilloscope cannot recall digital waveforms.
NOTE. The oscilloscope can save, but not
recall, RF acquisitions as .TIQ files. You can use
.T
IQ files w ith Tektronix SignalVu Vector Signal
Analysis software.
164 MDO4000 Series Oscilloscopes User Manual
