Performance Verification
4–2
TDS 340A, TDS 360 & TDS 380 Technical Reference
Refer to Figure 4–1: “Main menu” refers to the menu that labels the seven
menu buttons under the display. “Side menu” refers to the menu that labels
the five buttons to the right of the display. “Pop-up menu” refers to a menu
that pops up when a main menu button is pressed.
Where instructed to use a front-panel button or knob, select from a main or
side menu, or verify a readout or status message, the name of the button or
knob appears in boldface type.
Instructions for menu selection follow this format: FRONT PANEL
BUTTON ! Pop-Up (if necessary) ! Main Menu Button ! Side Menu
Button. For example, “Push TRIGGER MENU ! Type: Video ! Trig-
ger On ! Lines.”
STOP. This symbol denotes information you must read to do the procedure
properly.
Side Menu
Main Menu
Pop-Up Menu
Figure 4–1: Menu locations
