Tektronix TDS 360 Technical Reference

Performance Verification
TDS 340A, TDS 360 & TDS 380 Technical Reference
4–3
Test Equipment
The performance test procedures require external, traceable signal sources to
check instrument performance. If your test equipment does not meet the
minimum requirements listed in Table 4–1, your test results will be invalid.
Table 4–1: Test equipment
Item number
and description
Minimum requirements Example Purpose
1. Termination 50 W
(two required)
Impedance 50 W; connectors:
female BNC input, male BNC
output
Tektronix part number
011-0049-01
Checking delay between
channels
2. Cable, Precision Coaxial
(two required)
50 W , 91 cm (36 in), male to
male BNC connectors
Tektronix part number
012-0482-00
Signal interconnection
3. Connector,
Dual-Banana
Female-BNC to dual-banana Tektronix part number
103-0090-00
Several accuracy tests
4. Connector,
BNC “T”
Male-BNC to dual-female-BNC Tektronix part number
103-0030-00
Checking trigger sensitivity
5. Coupler,
Dual-Input
Female-BNC to dual-male-BNC Tektronix part number
067-0525-02
Checking delay between
channels
6. Generator, DC Calibration Variable amplitude to ±110 V;
accuracy to 0.1%
Wavetek 9100 Calibration
System with Option 250
Checking DC offset, gain, and
measurement accuracy
7. Generator,
Leveled Sine Wave,
Medium-Frequency
200 kHz to 250 MHz; variable
amplitude from 5 mV to 4 V
p-p
into 50 W
Wavetek 9100 Calibration
System with Option 250
Checking bandwidth and trigger
sensitivity
8. Generator,
Leveled Sine Wave,
High-Frequency
1
200 kHz to 400 MHz; variable
amplitude from 5 mV to 4 V
p-p
into 50 W
Rohde & Schwarz SMY with
URV 35 Power Meter and
NRV-Z8 Power Sensor
Checking bandwidth and trigger
sensitivity
9. Generator, Time Mark Variable marker frequency from
10 ms to 10 ns; accuracy within
2 ppm
Wavetek 9100 Calibration
System with Option 250
Checking sample rate and
delay-time accuracy
10. Probe, 10X,
included with this
instrument
A P6109B (TDS 340A), P6111B
(TDS 360), or P6114B
(TDS 380) probe
Tektronix number
P6109B (TDS 340A), P6111B
(TDS 360), or P6114B
(TDS 380)
Signal interconnection
1
The high frequency leveled sine wave generator is only required to verify the TDS 380, not the TDS 340A or TDS 360. If
you use the example equipment, refer to
Sine Wave Generator Leveling Procedure on page 4–20 for information on
obtaining a leveled output from an unleveled sine wave generator
. If available, you can use a Tektronix SG504 Leveled
Sine Wave Generator in place of the example equipment.
