Tenda O1 User Manual

130
7.3 Access control
7.3.1 Overview
The Access control function enables you to allow or disallow the wireless devices to access the
wireless network based on their MAC addresses. The device supports the following MAC address
filter rules:
− Disallow: It indicates that only the wireless devices with the specified MAC addresses
cannot access the wireless networks of the device.
− Allow: It indicates that only the wireless devices with the specified MAC addresses can
access the wireless networks of the device.
7.3.2 Configure access control
Configuration procedures:
Step 1 Start a web browser on the computer connected to the CPE, visit 192.168.2.1 and choose
Wireless > Access Control.
Step 2 Enable the Access Control function.
Step 3 Select a MAC address filter mode, Disallow or Allow.
Step 4 Enter the MAC addresses and click Add.
If the wireless devices to be controlled are connected to the CPE, click Add online devices to add them
to the access control list quickly.
Step 5 Click Save.
----End
Access Control List

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
