Tenda O1 User Manual

78
5.2 Wireless status
Log in to the web UI of the device, and choose Status. You can view wireless status here, including
working mode, SSID, security mode, and so on.
Parameters description
Name
Description
Working Mode
It specifies the working mode the device operates.
SSID
It specifies the wireless network name of this device.
Security Mode
It specifies the security mode of the wireless network of this device.
Channel/Radio Band
It specifies the channel and radio band used by this device to transmit radio signals.
Channel Bandwidth
It specifies the channel bandwidth of this device.
TX Power
It specifies the transmitted power of this device.
Wireless Client
It specifies the number of wireless clients connected to this device.
AP’s MAC Address
It displays the MAC address of the upstream device.

In AP, Router, Repeater, or P2MP mode, it displays the WLAN MAC address of the
CPE.

In Client, Universal Repeater or WISP mode, or when the bridging succeeds, it
displays the WLAN MAC address of the upstream AP. When the bridging fails, it
displays N/A.
Signal Strength
It displays the wireless signal strength of peer device.

In AP or Router mode, it displays the signal strength of the first device connected

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
