4 Quick setup
This module enables you to quickly configure the device or change the working mode of the CPE
to deploy your wireless network.
The CPE supports the following working modes:
− AP: In this mode, the device creates a wireless network based on the current wired
network.
− Client: In this mode, the device works as a wireless adapter to connect to the wireless
network of upstream AP.
− Universal Repeater: In this mode, this device extends an existing wireless network for
broader network coverage.
− WISP: In this mode, this device connects to a hotspot provided by ISP in wireless
manner, and provides the wireless network.
− Repeater: In this mode, the device connects to multiple wired networks through
wireless bridge, and provides wireless access point.
− P2MP: In this mode, the device connects to multiple wired networks through wireless
bridge, but does not provide wireless access point.
− Router: In this mode, the device connects to a modem in wired manner, and provides a
wireless network.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
