Tenda O1 User Manual

16
2 Login
2.1 Login
When you log in to the web UI at the first time or after the CPE is reset to factory settings, follow
the steps below:
Step 1 Connect the computer to the device.
1. Uncover the housing of the device.
2. Use an Ethernet cable to connect the PoE/LAN port of the CPE to the PoE port of the
included PoE adapter.
3. Use the included power adapter to connect the PoE adapter to a power source. The
LAN/WAN LED indicator of the device lights up.
4. Use an Ethernet cable to connect your computer to the LAN port of the PoE adapter.
Step 2 Start a web browser on your computer, and visit 192.168.2.1. Enter your user name and
password (default: admin), and click Login.
For the security of your network, you can change the login user name and password by choosing Tools >
Account.
PoE port

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
