Tenda O1 User Manual

134

If you specify the speed and duplex mode for the port manually, ensure that the speed and duplex
mode for peer port are the same with this port, or is set to auto negotiation.

The low speed mode can improve the transmission distance of the port. If you want to extend the
PoE power supply distance, you can change the speed mode to a low speed mode, such as 10
Mbps full duplex. And ensure that the speed mode for peer port is also 10 Mbps full duplex or auto
negotiation.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
