SME2-IS - Manual - 06 - 2021
CALIBRATION AND START-UP
Test
You can run functional tests of the selected output relays.
Use Up or Down
to scroll to the “Test” menu;
Press Right to enter the submenu; the following message displays: “Test state OFF”.
Use Down to scroll through the menu and select:
“Stop test Yes, Start test Yes, Test K1 Yes, Test K2 Yes, Test K3
Yes, Test K4 Yes, Test K5 Yes”
Example: to run a test on K1, proceed as follows:
• Select the “Start test? Yes>>” option.
• Press Right to enter the submenu; the following message displays: “TEST ON” and all LEDs turn
on.
• Press Left to return up the menu; the following message displays: “Start test Yes>>” and
all LEDs turn on.
• Select the relay you want to activate using Up or Down
until the respective message displays; e.g.
“Test K1? Yes>>”
• Press Right to run the test
• To terminate the test go to the menu “Stop test? Yes>>”, and press button Right
;
terminating
the test resets the relay and the LEDs go out. The test automatically stops after a minute in any
case.
Communication
The COMMUNICATION menu enables you to view the Addresses of the two ethernet ports.
With the MMI it is not possible to modify these parameters
CB open/close commands
By means of the (Open) or (Close) the circuit breaker commands may be issued.
These commands are enabled only in local operation (LED Local on).
Example:
• Press the button to open: appear the message: “OPEN CB? ENTER:YES RESET NO”
• Answer to the question ENTER: YES to conrm opening or RESET: NO to abort.
