SS0UE--02
SS--14
--SERVICE SPECIFICATIONS ENGINE FUEL
TORQUE SPECIFICATION
Part tightened N∙m kgf∙cm ft∙lbf
Nozzle holder body x Nozzle holder retaining nut 37 375 27
Injection nozzle x Cylinder head 54 540 40
Nozzle leakage pipe x Injection nozzle 30 300 22
Injection pump clamp x Intake manifold 6 65 56 in.∙lbf
Injection pipe x Injection nozzle 15 150 11
Injection pipe x Injection pump 15 150 11
Accelerator cable bracket x Intake pipe 20 200 15
Fuel inlet hollow screw x Injection pump body 36.8 375 27
Delivery valve holder x Distributive head 58.85 600 43
Distributive head plug x Distributive head 88 900 65
Fuel inlet pipe x injection pump Cap nut
Bolt
23
24.5
230
250
17
17
Fuel inlet pipe x Injection pump 23 230 17
Injection pump x Timing gear case 21 210 15
Fuel temp. sensor x Distributive head plug (No.2) 21.6 220 16.5
Pump stay x Injection pump 32 330 24
Pump stay x Cylinder block 21 210 15
Injection pump drive gear x Injection pump 64 650 47
