TP-Link Auranet EAP115-Wall User Manual

9
Channel:
Select the channel used by this device to improve wireless
performance. 1/2412MHz means the Channel is 1 and the frequency is
2412MHz. By default, channel is automatically selected.
Tx Power(EIRP): Enter the transmit power value. By default, the value is 20.
If the maximum transmit power is set to be larger than local regulation
allows, the maximum Tx power regulated will be applied in actual
situation.
NOTE
: In most cases, it is unnecessary to select maximum transmit
power. Selecting larger transmit power than needed may cause
interference to neighborhood. Also it consumes more power and will
reduce longevity of the device. Select a certain transmit power is
enough to achieve the best performance.
5.1.2 SSIDs
SSIDs can work together with switches supporting 802.1Q VLAN. The EAP can build up
to eight virtual wireless networks per radio for users to access. At the same time, it adds
different VLAN tags to the clients which connect to the corresponding wireless network.
It supports maximum 8 VLANs per radio. The clients in different VLAN cannot directly
communicate with each other.
Clients connected to the device via cable do not belong to any VLAN. Thus wired client
can communicate with all the wireless clients despite the VLAN settings.
Click in the Modify column, the following content will be shown.
Figure 5-4 SSIDs
Click to add up to 8 wireless networks per radio.

TP-Link Auranet EAP115-Wall Specifications

General

Frequency	2.4GHz
Signal Rate	Up to 300Mbps
Button	Reset Button
Certifications	CE, FCC, RoHS
Operating Temperature	0°C to 40°C (32°F to 104°F)
Wireless Standards	IEEE 802.11b/g/n
Power Supply	802.3af PoE
Interface	1 x 10/100 Mbps Ethernet Port (RJ45)
Wireless Functions	Multiple SSIDs
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Management	SNMP, Web-based Management, Centralized Management
Operating Humidity	10% to 90% non-condensing
Antenna Type	Internal Antenna
Dimensions	86.8 x 86.8 x 30.2 mm
