TP-Link Auranet EAP115-Wall User Manual

42
Band: Displays the band the client is in.
Access
Point:
Displays the name of the device to which the client is connected.
SSID: Displays the SSID the client is connected to.
SNR(dB): Signal to Noise Ratio, the power ratio between the received wireless
signal strength and the environmental noise strength. The bigger the
value of SNR, the better network performance the device provides.
CCQ(%): Displays the wireless Client Connection Quality (CCQ). CCQ refers to the
ratio of current effective transmission bandwidth and the theoretically
maximum available bandwidth. CCQ reflects the actual link condition.
Rate(Mbps): Displays the data rate at which the client transmits wireless packets.
Down(Byte): Displays the throughput of the downstream data.
Up(Byte): Displays the throughput of the upstream data.
Active Time: Displays the amount of time the client has been connected to the device.
6.3.2 Portal Authenticated Guest
The
Portal Authenticated Guest
displays information about clients that have set up
valid authentication.
Figure 6-13 Portal Authenticated Guest
MAC: Displays the MAC address of the authenticated client.
Band: Displays the band the authenticated client is in.
Access
Point:
Displays the name of the device to which the authenticated client is
connected
SSID: Displays the SSID the authenticated client is connected to.
SNR(dB): Signal to Noise Ratio, the power ratio between the received wireless
signal strength and the environmental noise strength. The bigger the
value of SNR, the better network performance the device provides.

TP-Link Auranet EAP115-Wall Specifications

General

Frequency	2.4GHz
Signal Rate	Up to 300Mbps
Button	Reset Button
Certifications	CE, FCC, RoHS
Operating Temperature	0°C to 40°C (32°F to 104°F)
Wireless Standards	IEEE 802.11b/g/n
Power Supply	802.3af PoE
Interface	1 x 10/100 Mbps Ethernet Port (RJ45)
Wireless Functions	Multiple SSIDs
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Management	SNMP, Web-based Management, Centralized Management
Operating Humidity	10% to 90% non-condensing
Antenna Type	Internal Antenna
Dimensions	86.8 x 86.8 x 30.2 mm
