TP-Link Auranet EAP115-Wall User Manual

47
Figure 7-6 Web Server Page
HTTPS: HTTPS (Hypertext Transfer Protocol Secure) is enabled by default.
Secure Server
Port:
Designate a secure server port for web server in HTTPS mode. By
default the port is 443.
Server Port: Designate a server port for web server in HTTP mode. By default the port
is 80.
Session
Timeout:
Set the session timeout time. If you do nothing with the web
management page within the timeout time, the system will log out
automatically. Please login again if you want
to go back to web
management page.
7.3 Management Access
Management Access Control allows you to configure up to four MAC addresses of the
hosts that are allowed to log in to the web management page of the EAP. Click Add PC’s
MAC and the MAC address of the current host will be added to MAC address list.
Following is the page of
Management Access
.

TP-Link Auranet EAP115-Wall Specifications

General

Frequency	2.4GHz
Signal Rate	Up to 300Mbps
Button	Reset Button
Certifications	CE, FCC, RoHS
Operating Temperature	0°C to 40°C (32°F to 104°F)
Wireless Standards	IEEE 802.11b/g/n
Power Supply	802.3af PoE
Interface	1 x 10/100 Mbps Ethernet Port (RJ45)
Wireless Functions	Multiple SSIDs
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Management	SNMP, Web-based Management, Centralized Management
Operating Humidity	10% to 90% non-condensing
Antenna Type	Internal Antenna
Dimensions	86.8 x 86.8 x 30.2 mm
