TP-Link Auranet EAP115-Wall User Manual

25
5.4 Scheduler
Scheduler allows you to configure rules with specific time interval for radios to operate,
which automates the enabling or disabling of the radio.
Figure 5-23 Scheduler Page
 Settings
Scheduler: Check the box to enable Scheduler.
Association Mode: Select Associated with SSID/AP, you can perform configurations on
the SSIDs/AP. The display of Scheduler Association is based on your
option here.
 Scheduler Profile Configuration
Follow the steps below to add rules.
Step 1:
Click , two tables will be shown.

TP-Link Auranet EAP115-Wall Specifications

General

Frequency	2.4GHz
Signal Rate	Up to 300Mbps
Button	Reset Button
Certifications	CE, FCC, RoHS
Operating Temperature	0°C to 40°C (32°F to 104°F)
Wireless Standards	IEEE 802.11b/g/n
Power Supply	802.3af PoE
Interface	1 x 10/100 Mbps Ethernet Port (RJ45)
Wireless Functions	Multiple SSIDs
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Management	SNMP, Web-based Management, Centralized Management
Operating Humidity	10% to 90% non-condensing
Antenna Type	Internal Antenna
Dimensions	86.8 x 86.8 x 30.2 mm
