TP-Link Auranet EAP115-Wall User Manual

33
Figure 5-34 Detected Rogue AP List
Click to scan rogue APs. Make sure you have enabled Rogue AP Detection
and saved the setting before you click the button.
Action: Click Known to move the AP to the Trusted AP List. After the configurations
are saved, the moved AP will not be displayed in the Detected Rogue AP
List.
MAC: The MAC address of the rogue AP.
SSID: The SSID of the rogue AP.
Band: Displays the frequency band which the wireless network of the rogue AP
operates at.
Channel: The channel on which the rogue AP is currently broadcasting.
Security: Displays the enabling or disabling of the security mode of the wireless
network.
Beacon
Interval:
The beacon interval used by the rogue AP.
Beacon frames are transmitted by an AP at regular intervals to announce
the existence of the wireless network. The default behavior is to send a
beacon frame once every 100 milliseconds (or 10 per second).
Signal: The strength of the radio signal emitting from the rogue AP.
5.6.3 Trusted AP List
Information about the trusted APs is displayed in the list.
Figure 5-35 Trusted AP List
Action: Click Unknown to move the AP out of the Trusted AP List.

TP-Link Auranet EAP115-Wall Specifications

General

Frequency	2.4GHz
Signal Rate	Up to 300Mbps
Button	Reset Button
Certifications	CE, FCC, RoHS
Operating Temperature	0°C to 40°C (32°F to 104°F)
Wireless Standards	IEEE 802.11b/g/n
Power Supply	802.3af PoE
Interface	1 x 10/100 Mbps Ethernet Port (RJ45)
Wireless Functions	Multiple SSIDs
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Management	SNMP, Web-based Management, Centralized Management
Operating Humidity	10% to 90% non-condensing
Antenna Type	Internal Antenna
Dimensions	86.8 x 86.8 x 30.2 mm
