TP-Link Auranet EAP115-Wall User Manual

34
MAC: The MAC address of the trusted AP.
SSID: The SSID of the trusted AP.
Band: Displays the frequency band which the wireless network of the trusted AP
operates at.
Channel: The channel on which the trusted AP is currently broadcasting.
Security: Displays the enabling or disabling of the security mode of the wireless
network.
5.6.4 Download/Backup Trusted AP List
You can import a list of trusted APs from a saved list which is acquired from another AP
or created from a text file. The AP whose MAC address is in the Trusted AP List will not
be detected as a rogue.
You can also backup a list and save it in your PC.
Figure 5-36 Download/Backup Trusted AP List
Save Action: Select Download (PC to AP) to import a trusted AP list to the device.
Select Backup (AP to PC) to copy the trusted AP list to your PC.
Source File
Name:
Click Browse and choose the path of a saved trusted AP list or to save
a trusted AP list.
File
Management:
Select Replace to import the list and replace the contents of the
Trusted AP List.
Select Merge to import the list and add the APs in the imported file to
the APs currently shown in the Trusted AP List
NOTE:
EAP device does not have any control over the APs in the Detected Rogue AP List.

TP-Link Auranet EAP115-Wall Specifications

General

Frequency	2.4GHz
Signal Rate	Up to 300Mbps
Button	Reset Button
Certifications	CE, FCC, RoHS
Operating Temperature	0°C to 40°C (32°F to 104°F)
Wireless Standards	IEEE 802.11b/g/n
Power Supply	802.3af PoE
Interface	1 x 10/100 Mbps Ethernet Port (RJ45)
Wireless Functions	Multiple SSIDs
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Management	SNMP, Web-based Management, Centralized Management
Operating Humidity	10% to 90% non-condensing
Antenna Type	Internal Antenna
Dimensions	86.8 x 86.8 x 30.2 mm
