TP-Link Auranet EAP115-Wall User Manual

20
2. External Web Portal
Figure 5-14 Portal Configuration_External RADIUS Server_External Web Portal
Authentication Type: Select External RADIUS Server.
RADIUS Server IP: Enter the IP address of the RADIUS server.
Port: Enter the port for authentication service.
RADIUS Password: Enter the shared secret of RADIUS server to log in to the RADIUS
server.
Portal Customization: Select External Web Portal.
External Web Portal
URL:
Enter the authentication login page’s URL, which is provided by
the remote portal server.
Please refer to No Authentication to configure Authentication Timeout, Redirect and
Redirect URL.
5.2.2 Free Authentication Policy
Free Authentication Policy allows clients to access network resources for free. On the
lower part of the Portal page you can configure and view free authentication policies.
Figure 5-15 Free Authentication Policy

TP-Link Auranet EAP115-Wall Specifications

General

Frequency	2.4GHz
Signal Rate	Up to 300Mbps
Button	Reset Button
Certifications	CE, FCC, RoHS
Operating Temperature	0°C to 40°C (32°F to 104°F)
Wireless Standards	IEEE 802.11b/g/n
Power Supply	802.3af PoE
Interface	1 x 10/100 Mbps Ethernet Port (RJ45)
Wireless Functions	Multiple SSIDs
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Management	SNMP, Web-based Management, Centralized Management
Operating Humidity	10% to 90% non-condensing
Antenna Type	Internal Antenna
Dimensions	86.8 x 86.8 x 30.2 mm
