29
5.5.1 AP EDCA Parameters
AP Enhanced Distributed Channel Access (EDCA) parameters affect traffic flowing from
the EAP device to the client station.
Figure 5-30 AP EDCA Parameters
Queue: Queue displays the transmission queue. By default, the priority from
high to low is Data 0, Data 1, Data 2, and Data 3. The priority may be
changed if you reset the EDCA parameters.
Data 0 (Voice)—Highest priority queue, minimum delay. Time-
sensitive data such as VoIP and streaming media are automatically
sent to this queue.
Data 1 (Video)—High priority queue, minimum delay. Time-sensitive
video data is automatically sent to this queue.
Data 2 (Best Effort)—Medium priority queue, medium throughput and
delay. Most traditional IP data is sent to this queue.
Data 3 (Background)—Lowest priority queue, high throughput. Bulk
data that requires maximum throughput and is not time-sensitive is
sent to this queue (FTP data, for example).
Arbitration Inter-
Frame Space:
A wait time for data frames. The wait time is measured in slots. Valid
values for Arbitration Inter-Frame Space are from 1 to 15.
Minimum
Contention
Window:
A list to the algorithm that determines the initial random backoff wait
time (window) for retry of a transmission.
This value cannot be higher than the value for the Maximum
Contention Window.
Maximum
Contention
Window:
The upper limit (in milliseconds) for the doubling of the random backoff
value. This doubling continues until either the data frame is sent or the
Maximum Contention Window size is reached.
This value must be higher than the value for the Minimum Contention
Window.
