50
router.
¾ Forbid Ping Packet from LAN Port - Enable or Disable forbidding Ping Packet to access
the router from the LAN port. The default value is disabled. If enabled, the ping packet from
the LAN port cannot access the router. (Defends against some viruses)
Click the Save button to save the settings.
Click the Blocked DoS Host Table button to display the DoS host table by blocking.
4.11 Static Routing
A static route is a pre-determined path that network information must travel to reach a specific
host or network. To add or delete a route, work in the area under the Static Routing page as
shown in Figure 4-44.
Figure 4-44 Static Routing
To add static routing entries:
1. Click the Add New button. (pop up Figure 4-45)
2.
Enter the following parameters.
¾ Destination IP Address - The Destination IP Address is the address of the network or host
that you want to assign to a static route.
¾ Subnet Mask - The Subnet Mask determines which portion of an IP Address is the network
portion, and which portion is the host portion.
¾ Default Gateway - This is the IP Address of the gateway device that allows for contact
between the router and the network or host.
3. Select Enabled or Disabled for this entry from the Status pull-down list.
4. Click the Save button to save the changes.
