5 - 34 RTHC-IOM-1C
Module Software Revision Levels
If <Enter> is selected the following screen can be
displayed 4 times with 4 different pairs of modules.
The modules and prefix software PN will be one of
the following:
Where xx is the software revision level as
communicated over the IPC bus. The entire formal
software part number for the particular module will be
displayed for each of the modules or devices shown
above (with the exception of the refrigerant monitor,
which will only display the Rev level). If a software
part number for a given module has not been read by
the CLD at any time since its last reset (RAM
initialization) it will display the words: “not available”
in place of the software PN.
Notes: These screens will display a line item for
every possible module in an RTHC system. If a
module fails during operation, the software revision
for that module will still appear on the CLD until after
a CLD power down reset.
Factory Settings
The following table contains the values and setpoints
for many menu settings as they are normally set in
the factory prior to shipping the unit. Some settings
are same as the ROM defaults (hardcoded settings
to which the UCP would default in the event of
memory errors). Other settings are made in the
factory and based on a particular chiller option or
application requested via the sales order. In the latter
case, the factory settings would differ. Remember,
before making changes to any settings, record the
original pre-set values so that the original settings
could be restored.
Press (Enter) To Display Software
Revision Levels Or (Next) To Continue
[Module x:] [Software PN]
[Module y:] [Software PN]
Chiller 6200-0079-xx
Starter 6200-0055-xx
Options 6200-0040-xx
Stepper 6200-0081-xx
TCI 6200-0093-xx
LCLD (local CLD) 6200-0091-xx
RCLD 6200-0091-xx
CCCLD (Complex
Character CLD)
6200-0092-xx
Refrigerant Monitor Rev -xx
Table 24
General Factory Settings
Operator Settings Front Panel Chilled Wtr Setpt 44.0
°
F
Front Panel Current Limit Setpt 100%
Chilled Water Reset Type DISABLE
Ice Building (per order or application)
Panel Ice Termination Setpt 27
°
F
Ice-to-Normal Cooling Timer 5 min
Chilled Water Setpt Source FRONT PANEL
Current Limit Setpt Source FRONT PANEL
Ice Termination Setpt Source FRONT PANEL
Setpoint Source Override NONE
Service Settings (Non-Passwd
Protect)
Language ENGLISH
Display Units ENGLISH
Decimal Places Displayed XXX.X
Display Menu Headings DISABLE
Differential to Start Setpt 5.0
°
F
Differential to Stop Setpt 5.0
°
F
Evap Pump Off Delay 1.0 MIN
To Next Page
