2 - 4 RTHC-IOM-1C
Table 6
Unit Weights (lb(kg)) (see Figure 5 )
Location (Point)
Unit Designator (corresponds to digits 6, 7, 12, 13, 16, 17 of unit model number)
B1B1B1 B1C1D1 B2B2B2 B2C2D2 C1B2C1 C1B3C2 C1E1F1 C2B3C2
A 2599
(1179)
3274
(1485)
2624
(1190)
3309
(1501)
3460
(1569)
3523
(1598)
4438
(2013)
3504
(1589)
B 2051
(930)
2369
(1075)
2076
(942)
2411
(1094)
2533
(1149)
2602
(1180)
3250
(1474)
2583
(1172)
C 1979
(898)
1823
(827)
2002
(908)
1860
(844)
2940
(1334)
3009
(1365)
3404
(1544)
2991
(1357)
D 3049
(1383)
2818
(1278)
3076
(1395)
2855
(1295)
4350
(1973)
4416
(2003)
4507
(2044)
4397
(1994)
Unit Wt (without
water)
9678
(4390)
10284
(4665)
9778
(4435)
10435
(4733)
13283
(6025)
13550
(6146)
15599
(7076)
13475
(6112)
Est. Water Wt
572 (259) 716 (325) 622 (282) 765 (347) 617 (280) 700 (318) 1101 (499) 700 (318)
Total Installed Wt
10250
(4649)
11000
(4990)
10400
(4717)
11200
(5080)
13900
(6307)
14250
(6466)
16700
(7574)
14175
(6431)
Table 7
Unit Weights (lb(kg)) (see Figure 5 )
Location (Point)
Unit Designator (corresponds to digits 6, 7, 12, 13, 16, 17 of unit model number)
C2D3E3 C2G1G1 D1D1E1 D1F1F2 D1G2G2 D2D2E2 D2F2F3 D2G3G3
A 3742
(1697)
5043
(2288)
3846
(1745)
4634
(2102)
5310
(2409)
3841
(1742)
4870
(2209)
5445
(2470)
B 2844
(1290)
4155
(1885)
2879
(1306)
3535
(1603)
4420
(2005)
2880
(1306)
3670
(1665)
4559
(2068)
C 3263
(1480)
4038
(1832)
3340
(1515)
3702
(1679)
4305
(1953)
3343
(1516)
3833
(1739)
4431
(2010)
D 4656
(2112)
5123
(2324)
4837
(2194)
4705
(2134)
5411
(2454)
4832
(2192)
4931
(2237)
5535
(2511)
Unit Wt (without
water)
14505
(6579)
18359
(8328)
14902
(6760)
16576
(7519)
19446
(8821)
14896
(6757)
17304
(7849)
19970
(9058)
Est. Water Wt
1045 (474) 1791 (812) 948 (430) 1324 (601) 1954 (886) 1004 (455) 1396 (633) 2130 (966)
Total Installed Wt
15550
(7055)
20150
(9142)
15850
(7189)
17900
(8119)
21400
(9707)
15900
(7189)
18700
(8482)
22100
(10024)
