Triumph Daytona 955i Handbook

21
General Information
Speedometer and
Odometer
The digital speedometer indicates
the road speed of the motorcycle.
The read-out displays the motorcycle
road speed in increments of one
kilometre (or mile) per hour.
In the speedometer face is the
electronic odometer, two trip meters
and the clock. For details of the
operation of the odometer, trip
meters and clock, please refer to the
following pages.
Tachometer
The tachometer shows the engine
speed in revolutions per minute -
rpm (r/min). On the right side of the
tachometer face is the 'red zone'.
Engine rpm (r/min) in the red zone
is above maximum recommended
engine speed and is also above the
range for best performance.
Odometer/Trip Meter/
Clock
1Odometer Display
2 Trip Meter 1 Display
3 Trip Meter 2 Display
4 Select Button
5 Reset Button
The odometer shows the total
distance that the motorcycle has
travelled.
There are two trip meters. Either trip
meter shows the distance that the
motorcycle has travelled since the
meter on display was last reset to
zero. Also located in the same
display frame is the clock.
Caution
Never allow engine RPM to enter
the 'red zone' as severe engine
damage may result.
000083
ODO
KM
km/h
TRIP
KM
km/h
TRIP
KM
km/h
jair
1
2
3
54

Triumph Daytona 955i Specifications

General

Displacement	955 cc
Bore x Stroke	79 x 65 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Transmission	6-speed
Rear Brakes	Single 220 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	190/50 ZR17
Width	720 mm (28.3 in)
Seat Height	815 mm (32.1 in)
Engine Type	Liquid-cooled, inline 3-cylinder
Max Torque	100 Nm (74 lb-ft) @ 8, 200 rpm
Final Drive	Chain
Frame	Aluminum beam
Front Suspension	43 mm inverted telescopic fork, adjustable
Rear Suspension	Monoshock, adjustable
Front Brakes	Twin 320 mm discs, 4-piston calipers
Fuel Capacity	21 litres (5.5 US gallons)
