Triumph Daytona 955i Handbook

36
General Information
NOTE
• Even if the clutch lever is
pulled to the handlebar, the
starter will not operate if
the side stand is down and a
gear is engaged.
Left Handlebar
Switches
1 Headlight dipswitch
2 Direction indicator switch
3 Horn button
4Pass Button
Headlight Dip Switch
High or low beam can be selected
with the headlight dip switch. To
select high beam, push the switch
forward. To select low beam, push
the switch rearwards. When the high
beam is turned on, the high beam
indicator light will illuminate.
NOTE
• A lighting ON/OFF switch is
not fitted to this model. The
headlight, rear light and
licence plate light all
function automatically when
the ignition is turned to the
ON position.
Direction Indicator Switch
When the indicator switch is pushed
to the left or right and released, the
corresponding direction indicators
will flash on and off. To turn off the
indicators, push and release the
switch.
Horn Button
When the horn button is pushed,
with the ignition switch turned to the
'ON' position, the horn will sound.
Pass Button
When the pass button is pressed the
headlight main beam will be
switched on. It will remain on as
long as the button is held in and will
turn off as soon as the button is
released.
ccmg
4
3
2
1

Triumph Daytona 955i Specifications

General

Displacement	955 cc
Bore x Stroke	79 x 65 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Transmission	6-speed
Rear Brakes	Single 220 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	190/50 ZR17
Width	720 mm (28.3 in)
Seat Height	815 mm (32.1 in)
Engine Type	Liquid-cooled, inline 3-cylinder
Max Torque	100 Nm (74 lb-ft) @ 8, 200 rpm
Final Drive	Chain
Frame	Aluminum beam
Front Suspension	43 mm inverted telescopic fork, adjustable
Rear Suspension	Monoshock, adjustable
Front Brakes	Twin 320 mm discs, 4-piston calipers
Fuel Capacity	21 litres (5.5 US gallons)
