Triumph Daytona 955i Handbook

61
Maintenance and Adjustment
Side Panel
Daytona 955i
Side Panel Removal
Remove the seats.
Remove the infill panels.
Disconnect the battery, negative
(black) lead first.
Release the fixings as shown in the
diagram above.
Lift and withdraw the side panel
assembly in a rearward direction.
Side Panel Refitting
Reverse the removal procedure with
the exception of the following.
Reconnect the battery positive (red)
lead first.
Tighten the panel fixings to 3Nm.
Refit the infill panels.
Speed Triple
Side Panel Removal
Remove the seats.
Disconnect the battery, negative
(black) lead first.
Release the fixings as shown in the
diagram above.
Lift and withdraw the side panel.
Side Panel Refitting
Reverse the removal procedure with
the exception of the following.
Reconnect the battery positive (red)
lead first.
Tighten the panel fixings to 3Nm.
ccof
ccqd

Triumph Daytona 955i Specifications

General

Displacement	955 cc
Bore x Stroke	79 x 65 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Transmission	6-speed
Rear Brakes	Single 220 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	190/50 ZR17
Width	720 mm (28.3 in)
Seat Height	815 mm (32.1 in)
Engine Type	Liquid-cooled, inline 3-cylinder
Max Torque	100 Nm (74 lb-ft) @ 8, 200 rpm
Final Drive	Chain
Frame	Aluminum beam
Front Suspension	43 mm inverted telescopic fork, adjustable
Rear Suspension	Monoshock, adjustable
Front Brakes	Twin 320 mm discs, 4-piston calipers
Fuel Capacity	21 litres (5.5 US gallons)
