Triumph Daytona 955i Handbook

23
General Information
Warning Displays
Low Oil Pressure Warning
1 Low Oil Pressure Display
If sufficient oil pressure is present,
the display will not appear.
With the engine running, if the
engine oil pressure becomes
dangerously low, the low oil pressure
symbol in the temperature display
will flash. In addition, the low
pressure warning light in the
tachometer will illuminate.
The low oil pressure symbol will flash
and the low oil pressure warning in
the tachometer will illuminate if the
ignition is switched on without
running the engine.
• If the coolant temperature is
below 40
o
C, the word ‘LO’ will
also appear in the display. This
does not indicate low oil
pressure. It does, however,
indicate that the coolant
temperature is low.
Caution
Stop the engine immediately if the
low oil pressure warning light
illuminates. Do not restart the
engine until the fault has been
rectified.
Severe engine damage will result
from running the engine when the
low oil pressure warning light is
illuminated.
LO
jaiv
1

Triumph Daytona 955i Specifications

General

Displacement	955 cc
Bore x Stroke	79 x 65 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Transmission	6-speed
Rear Brakes	Single 220 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	190/50 ZR17
Width	720 mm (28.3 in)
Seat Height	815 mm (32.1 in)
Engine Type	Liquid-cooled, inline 3-cylinder
Max Torque	100 Nm (74 lb-ft) @ 8, 200 rpm
Final Drive	Chain
Frame	Aluminum beam
Front Suspension	43 mm inverted telescopic fork, adjustable
Rear Suspension	Monoshock, adjustable
Front Brakes	Twin 320 mm discs, 4-piston calipers
Fuel Capacity	21 litres (5.5 US gallons)
