Triumph Daytona 955i Handbook

38
General Information
Fuel Tank Cap
1Fuel tank cap
2Key
To open the fuel tank cap, lift up the
flap covering the lock itself. Insert
the key into the lock and turn the
key clockwise.
To close and lock the cap, push the
cap down into place with the key
inserted, until the lock 'clicks' into
place. Withdraw the key and close
the key cover.
Filling the Fuel Tank
Avoid filling the tank in rainy or
dusty conditions where airborne
material can contaminate the fuel.
Fill the fuel tank slowly to help
prevent spillage. Do not fill the tank
to a level above the bottom of the
filler neck. This will ensure there is
enough air space to allow for fuel
expansion if the fuel inside the tank
expands through absorption of heat
from the engine or from direct
sunlight.
1 Fuel filler neck
2 Maximum fuel level
3Air space
Caution
Closing the cap without the key
inserted will damage the cap, tank
and lock mechanism.
1
2
cbmm
Caution
Contaminated fuel may cause
damage to fuel system
components.
1 2 3
cbdf

Triumph Daytona 955i Specifications

General

Displacement	955 cc
Bore x Stroke	79 x 65 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Transmission	6-speed
Rear Brakes	Single 220 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	190/50 ZR17
Width	720 mm (28.3 in)
Seat Height	815 mm (32.1 in)
Engine Type	Liquid-cooled, inline 3-cylinder
Max Torque	100 Nm (74 lb-ft) @ 8, 200 rpm
Final Drive	Chain
Frame	Aluminum beam
Front Suspension	43 mm inverted telescopic fork, adjustable
Rear Suspension	Monoshock, adjustable
Front Brakes	Twin 320 mm discs, 4-piston calipers
Fuel Capacity	21 litres (5.5 US gallons)
