Triumph Daytona 955i Handbook

29
General Information
Coolant Temperature
Gauge
1 Coolant Temperature Gauge
The coolant temperature gauge
indicates the temperature of the
engine coolant.
When the ignition is switched on, all
10 bars of the display will be shown.
When the engine is started from cold
the display will show 1 bar. As the
temperature increases more bars
will be shown in the display.
The normal temperature range is
between 3 and 6 bars.
If the coolant temperature becomes
too high the display will show 9 bars
and will start to flash. The high
coolant temperature warning light in
the tachometer will also be
illuminated.
If the coolant temperature increases
further, all 10 bars of the display will
flash. The high temperature warning
light in the tachometer will remain
illuminated.
Gear Change Lights
1 Gear change lights
2Display screen
3 Scroll button
4Set button
5 Trip button
The gear change lights provide a
visual indication of when to change
gear. The set change-up speed at
which the lights operate can be set
for rider preference.
The lights will illuminate in sequence
1250 rpm before the set change-up
speed in the following order:
ccnd
1
Caution
Do not continue to run the engine
if either of the high temperature
warnings are displayed as severe
engine damage may result.
ccne
3
261
4 5

Triumph Daytona 955i Specifications

General

Displacement	955 cc
Bore x Stroke	79 x 65 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Transmission	6-speed
Rear Brakes	Single 220 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	190/50 ZR17
Width	720 mm (28.3 in)
Seat Height	815 mm (32.1 in)
Engine Type	Liquid-cooled, inline 3-cylinder
Max Torque	100 Nm (74 lb-ft) @ 8, 200 rpm
Final Drive	Chain
Frame	Aluminum beam
Front Suspension	43 mm inverted telescopic fork, adjustable
Rear Suspension	Monoshock, adjustable
Front Brakes	Twin 320 mm discs, 4-piston calipers
Fuel Capacity	21 litres (5.5 US gallons)
