Triumph Daytona 955i Handbook

22
General Information
To switch between the odometer and
trip meter display modes, press and
release the left hand ‘select’ button.
The display will scroll through in the
order:
•Odometer,
• Trip meter 1,
• Trip meter 2,
•Clock
To reset either of the trip meters,
select and display the trip meter to
be zeroed then press the right hand
‘reset’ button to set the display to
zero.
Clock Adjustment
1Clock Display
2 Hours Read-out
3Minutes Read-out
4Select Button
5 Reset Button
To reset the clock, select the clock
display and press both ‘select’ and
‘reset’ buttons together. After a short
time, the clock’s hour display will
start to flash.
To reset the hour display, ensure
that the hour display is still flashing
then depress the ‘reset’ button to
change the setting. Each individual
press will change the setting by one
digit. If the button is held, the
display will continuously scroll
through in single digit increments.
When the correct hour display is
shown, press the ‘select’ button. The
minutes display will begin to flash.
The minutes display is adjusted in
the same way as for the hours.
Once both hours and minutes are
correctly set, press the ’select’
button to confirm the setting. The
display will cease to flash.
km/h
km/h km/h
jais
32
14 5

Triumph Daytona 955i Specifications

General

Displacement	955 cc
Bore x Stroke	79 x 65 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Transmission	6-speed
Rear Brakes	Single 220 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	190/50 ZR17
Width	720 mm (28.3 in)
Seat Height	815 mm (32.1 in)
Engine Type	Liquid-cooled, inline 3-cylinder
Max Torque	100 Nm (74 lb-ft) @ 8, 200 rpm
Final Drive	Chain
Frame	Aluminum beam
Front Suspension	43 mm inverted telescopic fork, adjustable
Rear Suspension	Monoshock, adjustable
Front Brakes	Twin 320 mm discs, 4-piston calipers
Fuel Capacity	21 litres (5.5 US gallons)
