TYM T233 HST User Manual

SECTION 5. EARTHING POINT
Fig.10-24
1) Front axle bracket (RH)
Earthed at upper tapped hole in the axle bracket.
3)
Earthed at upper tapped hole in the dash panel.
1)Front axle bracket
3) In the dash cover
10-11
3)
Earthed at upper tapped hole in the dash panel.
Fig.10-25
Fig.10-26
2) Contact surfaces of the axle bracket and engine
where they tightened together

TYM T233 HST Specifications

General

Brand	TYM
Model	T233 HST
Category	Tractor
Language	English
